Star Formation in nearby Nebulae

Star formation is one of the least understood processes in astrophysics. It is difficult to formulate a general theory for star formation in part because of the wide range of physical processes involved (e.g. Krumholz et al. 2011). The interstellar gas out of which stars form is a turbulent plasma governed by magnetic fields, radiative processes and further influenced by gravity. The behavior of star-forming clouds is further influenced by a wide variety of chemical processes, including formation and destruction of molecules and dust grains. As a result of these complexities, we are still limited to making empirical measurements to constrain how stars form from the gas, and one of the most basic measurements is the mass of a star forming region, and the rate at which this gas is converted in to stars (the star formation efficiency; e.g. Murray et al. 2010 ).

Hydrogen is the most abundant element. At the high densities where stars form, hydrogen tends to be molecular rather than atomic, although H2 is extremely hard to observe directly. Instead we are forced to observe proxies. The most straightforward conceptually is dust. Interstellar gas clouds are always mixed with dust, and the dust grains absorb background starlight.

The image below shows a region around the pillars of creation, the star forming region made famous by the Hubble Space Telescope. Notice how the stars all appear red -- a consence of the interstellar dust and gas preferentially absorbing blue wavelengths.

The goal of this project is to make observations and measure the colours of stars embedded in a star forming region, and use the colour excess to infer the hydrogen mass of the cloud. Here are some suggestions for the project and measurements that you may wish to think about:

1. identify a suitable target (or targets) and the conduct observations. The stars in the region you have identified must have measured spectral types (since we will need to compare the observed colours to their intrinsic colours). The nebular in M42 is a good target (e.g. Muench et al. 2008), but there may be others. For the observations, you will need to choose your observing time carefully. Remember, these are 16-bit detectors and saturate with 65,536 counts. Do you need to worry about the CCD linearity? (and if so how can you measure this?). Conduct observations in B and V (adding R will make a nice colour image!)

2. Stack the images to construct a mosaic from which the measurements can be made. The stacking procedure is detailed here.

3. Derive the zero-point for the image. Information about the Python script which can be used to zero-point image can be found here.

4. Use GAIA to measure the magnitude of the stars from the mosaic, applying the zero point. Also, record the number of counts from the star and sky background. Which dominates?

5. Calibrate the CCD to test whether the images are read-noise-, dark-current-, sky-noise-, or photon-noise- limited. You may want to check that signal is linear. For the read-noise, you could obtain a a set (short) dark images from which you can check the noise in a single pixel (or set of pixels). For the dark current, measure the signal in "dark" mode as a function of exposure time. What is the Bias level? Check the linearity to ensure your magnitudes are reliable? Measure the gain (why might this be important?)

6. With all of the calibrations made, calculate the error on the magnitude. Are the errors dominated by photon-noise, sky-noise, read-noise, or dark current?

7. Look up the spectral types of the stars. For M42, the spectral types for the stars in Trapezium can be found in Simon-Diaz et al. (2006).

8. Find the theoretical colours of stars with the same spectral types, and measure the colour excess:

    E(B-V) = (B-V)observed-(B-V)intrinsic

   Calculate the dust redenning using a calibration between colour excess and redenning

    AV = R x E(B-V)

   (for the coefficient, R, see Calzetti et al. (2000)

9. The Hydrogen column density can be estimated from the dust redenning (AV) using the calibration between N(H) and AV in Guver et al. 2009.

10. Find the spatial extent of M42, and integrate to derive the total Hydrogen mass. Note the size is much bigger than the field of view of the CCD.

11. What other corrections might need to be applied to the measurements to estimate the total mass (i.e. what assumption did the calculate above involve?)

12. Estimate the gas depletion time for the cloud. i.e. how long before M42 has consumed all of its gas? The star formation rate can be estimated from the total luminosity via

    SFR(Moyr-1) = 4.5x10-37 x Lbol (W) (Kennicutt 1998)

    The total flux of M42 is f=4x10-12W/cm2 (Harwit et al. 1982)

13. Are the observations limited by random or systematic uncertainties? Are the derived properties (mass, lifetime) dominated by random or systematic uncertainties? How could the experiment be improved to derive a more reliable answer?
